UCAV situation assessment method based on C-LSHADE-Means and SAE-LVQ

doi:10.23919/JSEE.2023.000062

Journal of Systems Engineering and Electronics ›› 2023, Vol. 34 ›› Issue (5): 1235-1251.doi: 10.23919/JSEE.2023.000062

• Systems Engineering • Previous Articles Next Articles

UCAV situation assessment method based on C-LSHADE-Means and SAE-LVQ

Lei XIE¹(), Shangqin TANG¹(), Zhenglei WEI²^,*(), Yongbo XUAN³(), Xiaofei WANG³()

¹ Institute of Aeronautics Engineering, Air Force Engineering University, Xi’an 710038, China
² China Aerodynamics Research & Development Center, Mianyang 621000, China
³ Blue Sky Innovation Center for Frontier Science, Beijing 100000, China

Received:2021-02-24 Online:2023-10-18 Published:2023-10-30
Contact: Zhenglei WEI E-mail:310370487@qq.com;630909448@qq.com;zhenglei_wei@126.com;398791736@qq.com;wxf825421673@163.com
About author:
XIE Lei was born in 1997. He received his bachelor degree in arms engineering and master degree in armament science and technology from Air Force Engineering University, Xi’an, China. He is currently pursuing his doctor degree in Air Force Engineering University, Xi’an, Shaanxi, China. His research interests include air combat, intelligent optimization algorithm, maneuvering decision, and situation assessment. E-mail: 310370487@qq.com

TANG Shangqin was born in 1984. He received his bachelor and Ph.D. degrees in arms engineering from Air Force Engineering University in 2007 and 2013, respectively. His research interests include air combat maneuver decision, intention recognition, and situation assessment.E-mail: 630909448@qq.com

WEI Zhenglei was born in 1991. He received his B.S., M.S., and Ph.D. degrees in armament science and technology from Air Force Engineering University. He is an engineer in China Aerodynamics Research & Development Center. His research interests include maneuvering prediction and maneuvering decision. E-mail: zhenglei_wei@126.com

XUAN Yongbo was born in 1984. He received his Ph.D. degree from Air Force Engineering University in 2012. He is an engineer in Beijing Blue Sky Innovation Center for Frontier Science. His research interest is general technology. E-mail: 398791736@qq.com

WANG Xiaofei was born in 1990. He received his Ph.D. degree of weapon science and technology from Air Force Engineering University in 2020. He is an engineer in Beijing Blue Sky Innovation Center for Frontier Science. His research interests are evolutionary algorithms and UCAV air combat decision. E-mail: wxf825421673@163.com
Supported by:
This work was supported by the Natural Science Foundation of Shaanxi Province (2020JQ-481;2021JM-224), and the Aeronautical Science Foundation of China (201951096002).

Abstract

Abstract:

The unmanned combat aerial vehicle (UCAV) is a research hot issue in the world, and the situation assessment is an important part of it. To overcome shortcomings of the existing situation assessment methods, such as low accuracy and strong dependence on prior knowledge, a data-driven situation assessment method is proposed. The clustering and classification are combined, the former is used to mine situational knowledge, and the latter is used to realize rapid assessment. Angle evaluation factor and distance evaluation factor are proposed to transform multi-dimensional air combat information into two-dimensional features. A convolution success-history based adaptive differential evolution with linear population size reduction-means (C-LSHADE-Means) algorithm is proposed. The convolutional pooling layer is used to compress the size of data and preserve the distribution characteristics. The LSHADE algorithm is used to initialize the center of the mean clustering, which overcomes the defect of initialization sensitivity. Comparing experiment with the seven clustering algorithms is done on the UCI data set, through four clustering indexes, and it proves that the method proposed in this paper has better clustering performance. A situation assessment model based on stacked autoencoder and learning vector quantization (SAE-LVQ) network is constructed, and it uses SAE to reconstruct air combat data features, and uses the self-competition layer of the LVQ to achieve efficient classification. Compared with the five kinds of assessments models, the SAE-LVQ model has the highest accuracy. Finally, three kinds of confrontation processes from air combat maneuvering instrumentation (ACMI) are selected, and the model in this paper is used for situation assessment. The assessment results are in line with the actual situation.

Key words: unmanned combat aerial vehicle (UCAV), situation assessment, clustering, K-means, stacked autoencoder, learning vector quantization

Lei XIE, Shangqin TANG, Zhenglei WEI, Yongbo XUAN, Xiaofei WANG. UCAV situation assessment method based on C-LSHADE-Means and SAE-LVQ[J]. Journal of Systems Engineering and Electronics, 2023, 34(5): 1235-1251.

Figures/Tables 26

Fig 1

Fig 2

Fig 3

Fig 4

Fig 5

Fig 6

Fig 7

Fig 8

Fig 9

Table 1

Fig 10

Table 2

Cluster evaluation index"

Index	Formula	Description
Ac	$A = \displaystyle \frac{ { {N_r} } }{N} \times 100$	$ {N_r} $ is the number of correct sample classifications; $ N $ is the total number of samples; the larger the Ac, the better the clustering effect.
Sil	${\rm{SI}} = \displaystyle \frac{1}{N}\displaystyle \sum_{i = 1}^N {\frac{ { {b_i} - {a_i} } }{ {\max ({b_i},{a_i})} } }$ , ${a_i} = \displaystyle \frac{1}{ { {N_k} } }\displaystyle \sum_{ {x_j} \in {c_k} } {{\rm{dist}}} ({x_i},{x_j})$ ${b_i} = {\mathop { {\rm{min} } }\limits_{h \in \left\{ {1,\cdots,k} \right\},h \ne k{\rm{ } } } }(\displaystyle \frac{1}{ { {N_k} } }\displaystyle \sum_{ {x_j} \in {c_k} } { {\rm{dist} } } ({x_i},{x_j}))$	$ a $ represents the average distance from the sample to other samples of the same category, $ b $ represents the shortest average distance from the sample to other samples of different categories, $ {\rm{SI}} \in [ - 1,1] $ , the larger the $ {\rm{SI}} $ , the better the clustering effect.
DB	${\rm{DB} } = \dfrac{1}{k}\displaystyle \sum_{j = 1}^k {\max \frac{ {s({c_k}) + s({c_r})} }{ { {\rm{dist} }({c_k},{c_l} )} }}$ $s({c_k}) = \displaystyle \frac{1}{n}\displaystyle \sum_{i = 1}^n {d({x_i},{c_k})}$	DB represents the proportion of cluster scatter between cluster separation.
CH	${\rm{CH} }(k) = \displaystyle \frac{ { {\rm{BGSS} } } }{ { {\rm{WGSS} } } } \times \frac{ {n - k} }{ {k - 1} }$ ${\rm{WGSS} } = \displaystyle \frac{1}{2}\displaystyle \sum_{i = 1}^k {({n_i} - 1)\overline d_i^2 }$ ${\rm{BGSS}} = \displaystyle \frac{1}{2}[(k - 1)\overline d^2 +\displaystyle \sum_{i = 1}^k {({n_i} - 1)(\overline d^2 - \overline d_i^2 )} ]$	$\overline {d}_i^2$ represents the average distance of samples in the ith cluster, $\overline { d}^2$ represents the average distance of all samples, and the larger the $ {\rm{CH}} $ , the better the clustering effect.

Table 2

Table 3

Fig 11

Table 4

Fig 12

Fig 13

Fig 14

Fig 15

Table 5

Fig 16

Table 6

Table 7

Fig 17

Fig 18

Fig 19

References 48

1	LUNSFORD I, BRADLEY T H Evaluation of unmanned aerial vehicle tactics through the metrics of survivability. Journal of Defense Modeling and Simulation-Applications Methodology Technology, 2021, 19 (4): 855- 864.
2	DONG Y Q, AI J L, LIU J Q Guidance and control for own aircraft in the autonomous air combat: a historical review and future prospects. Journal of Aerospace Engineering, 2019, 133 (16): 5943- 5991.
3	YANG K B, DONG W H, CAI M, et al UCAV air combat maneuver decisions based on a proximal policy optimization algorithm with situation reward shaping. Electronics, 2022, 11 (16): 2602. doi: 10.3390/electronics11162602
4	FU L, CHANG F H, XU J, et al. Research of air combat situation assessment method. Proc. of the International Conference on Digital Manufacturing & Automation, 2012. DOI: 10.1109/ICDMA.2012.155.
5	ZHAO K X, HUANG C Q. Air combat situation assessment for UAV based on improved decision tree. Proc. of the 30th Chinese Control and Decision Conference, 2018. DOI: 10.1109/CCDC.2018.8407414.
6	ZHANG H P, HUANG C Q Maneuver decision-making of deep learning for UCAV thorough azimuth angles. IEEE Access, 2020, 8, 12976- 12987. doi: 10.1109/ACCESS.2020.2966237
7	ZHANG C K, CHENG Y, HE Z Q, et al. Method of dynamic air combat threat evaluation based on time series. Proc. of the 35th Chinese Control Conference, 2016. DOI:10.1109/ChiCC.2016.7554892.
8	YING Z, TANG Y C, ZHAO X Z Novel uncertainty management approach for air combat situation assessment based on improved belief entropy. Entropy, 2019, 21 (5): 495- 506. doi: 10.3390/e21050495
9	XU X M, YANG R N, FU Y. Situation assessment for air combat based on novel semi-supervised naive Bayes. Journal of Systems Engineering and Electronics, 2018, 29(4): 768−779.
10	LU C G, ZHOU Z L, LIU H Q, et al. Situation assessment of far-distance attack air combat based on mixed dynamic bayesian networks. Proc. of the 37th Chinese Control Conference, 2018. DOI: 10.23919/ChiCC.2018.8483074.
11	HE X M, ZU W, CHANG H X, et al. Autonomous maneuvering decision research of UAV based on experience knowledge representation. Proc. of the Chinese Control and Decision Conference, 2016. DOI: 10.1109/CCDC.2016.7530973.
12	XUAN Y B, HUANG C Q, LI W X Air combat situation assessment by gray fuzzy Bayesian network. Applied Mechanics and Materials, 2011, 69, 114- 119. doi: 10.4028/www.scientific.net/AMM.69.114
13	SUN Z L, YANG H W, HU W D, et al. Situation assessment for air combat based on the Bayesian networks technology. Proceedings of SPIE - The International Society for Optical Engineering, 2006. DOI: 10.1117/12.657673.
14	NARAYANA R P, SUDESH K K, GIRIJA G, et al. Situation and threat assessment in BVR combat. Proc. of the AIAA Guidance, Navigation & Control Conference, 2011. DOI: 10.2514/6.2011-6241.
15	MA S D, YANG G Q, ZHANG H Z, et al. Target threat level assessment technology based on cloud model and Bayesian revision in air combat simulation. Proc. of the 35th Chinese Control Conference, 2016. DOI: 10.1109/ChiCC.2016.7554903.
16	VIRTANEN K, RAIVIO T Modeling pilot ’s sequential maneuvering decisions by a multistage influence diagram. Journal of Guidance, Control, and Dynamics, 2004, 27 (4): 665- 677. doi: 10.2514/1.11167
17	KAI V, JANE K, TUOMAS R Modeling air combat by a moving horizon influence diagram game. Journal of Guidance, Control, and Dynamics, 2006, 29 (5): 1080- 1091. doi: 10.2514/1.17168
18	ALAM S, DOBBIE G, KOH Y S, et al Research on particle swarm optimization-based clustering: a systematic review of literature and techniques. Swarm and Evolutionary Computation, 2014, 17, 1- 13. doi: 10.1016/j.swevo.2014.02.001
19	NANDA S J, PANDA G. A survey on nature inspired metaheuristic algorithms for partitional clustering. Swarm and Evolutionary Computation, 2014, 16: 1−18.
20	JOSE G A, GOMEZ F W Automatic clustering using nature-inspired metaheuristics: a survey. Applied Soft Computing, 2016, 41, 192- 213. doi: 10.1016/j.asoc.2015.12.001
21	HRUSCHK E R, CAMPELLO R J G B, FREITAS A A, et al A survey of evolutionary algorithms for clustering. IEEE Trans. on Systems, Man, and Cybernetics: Part C (Applications and Reviews), 2009, 39 (2): 133- 155. doi: 10.1109/TSMCC.2008.2007252
22	INKAYA T, KAYALGIL S, ZDEMIREL N E Ant colony optimization-based clustering methodology. Applied Soft Computing, 2015, 28, 301- 311. doi: 10.1016/j.asoc.2014.11.060
23	REFAAT M M, ALEEM S H E A, ATIA Y, et al Multi-stage dynamic transmission network expansion planning using LSHADE-SPACMA. Applied Sciences, 2021, 11 (5): 2155. doi: 10.3390/app11052155
24	MOHAMED A W, HADI A A, FATTOUH A M, et al. LSHADE with semi-parameter adaptation hybrid with CMA-ES for solving CEC 2017 benchmark problems. Proc. of the IEEE Congress on Evolutionary Computation, 2017. DOI: 10.1109/CEC.2017.7969307.
25	ZHANG J Q, SANDERSON A C JADE: adaptive differential evolution with optional external archive. IEEE Trans. on Evolutionary Computation, 2009, 13 (5): 945- 958. doi: 10.1109/TEVC.2009.2014613
26	ELLIACKIN F, MARIANA M, HUGO V S, et al. Swarm intelligence for clustering—a systematic review with new perspectives on data mining. Engineering Applications of Artificial Intelligence, 2019, 82: 313−329.
27	BRUSCO M J, STEINLEY D A comparison of heuristic procedures for minimum within-cluster sums of squares partitioning. Psychometrika, 2007, 72 (4): 583- 600. doi: 10.1007/s11336-007-9013-4
28	WANG Y, LI H X, HUANG T W, et al Differential evolution based on covariance matrix learning and bimodal distribution parameter setting. Applied Soft Computing Journal, 2014, 18 (1): 232- 247.
29	STORN R Differential evolution—a simple and efficient heuristic for global optimization over continuous space. Journal of Global Optimization, 1997, 11, 341- 359. doi: 10.1023/A:1008202821328
30	XUE J K, SHEN B A novel swarm intelligence optimization approach: sparrow search algorithm. Systems Science & Control Engineering, 2020, 8 (1): 22- 34.
31	LI X G, ZHU J, SHI H R, et al Surface defect detection of seals based on k-means clustering slgorithm and particle swarm optimization. Scientific Programming, 2021, 2021, 3965247.
32	HEIDARI A A, SEYEDALI M, HOSSAM F, et al Harris hawks optimization: algorithm and applications. Future Generation Computer Systems, 2019, 97 (12): 849- 872.
33	KOHLI M, ARORA S Chaotic grey wolf optimization algorithm for constrained optimization problems. Journal of Computational Design and Engineering, 2018, 5 (4): 458- 472. doi: 10.1016/j.jcde.2017.02.005
34	ESMAT R, HOSSEIN N, SAEID S GSA: a gravitational search algorithm. Information Sciences, 2009, 179 (13): 2232- 2248. doi: 10.1016/j.ins.2009.03.004
35	HANCER E, KARABOGA D. A comprehensive survey of traditional, merge-split and evolutionary approaches proposed for determination of cluster number. Swarm and Evolutionary Computation, 2017, 32: 49−67.
36	GAO J, ZHAO L, CHEN Z K, et al. ICFS: an improved fast search and find of density peaks clustering algorithm. Proc. of the 14th International Conference on Dependable, Autonomic and Secure Computing, 2016. DOI: 10.1109/DASC-PICom-DataCom-CyberSciTec.2016.103.
37	WANG Z Q, YU Z W, CHEN C L P, et al Clustering by local gravitation. IEEE Trans. on Cybernetics, 2017, 48 (5): 1383- 1396.
38	REZAEE M J, ESHKEVARI M, SABERI M, et al GBK-means clustering algorithm: an improvement to the K-means algorithm based on the bargaining game. Knowledge-Based Systems, 2021, 213, 106672. doi: 10.1016/j.knosys.2020.106672
39	ZHANG Z R. Research on key technologies of autonomous close-range air combat for unmanned combat aircraft. Xi’an: Air Force Engineering University, 2019. (in Chinese)
40	TAN S X An intrusion detection method based on stacked autoencoder and support vector machine. Journal of Physics: Conference Series, 2020, 1453 (1): 012010- 012016. doi: 10.1088/1742-6596/1453/1/012010
41	ZABALZA J, REN J C, ZHENG J B, et al Novel segmented stacked autoencoder for effective dimensionality reduction and feature extraction in hyperspectral imaging. Neurocomputing, 2016, 185, 1- 10. doi: 10.1016/j.neucom.2015.11.044
42	LU X T, WANG H, DONG W S, et al Learning a deep vector quantization network for image compression. IEEE Access, 2019, 7, 118815- 118825. doi: 10.1109/ACCESS.2019.2934731
43	KAYAMA M, SUGITA Y, MOROOKA Y Sensor diagnosis system combining immune network and learning vector quantization. Electrical Engineering in Japan, 1996, 117 (5): 44- 56. doi: 10.1002/eej.4391170505
44	LIU J Y, LIANG Y C, SUN X Y. Application of learning vector quantization network in fault diagnosis of power transformer. Proc. of the International Conference on Mechatronics & Automation, 2009. DOI: 10.1109/ICMA.2009.5246676.
45	TANG F Z, TINO P, YU H B. Generalized learning vector quantization with log-Euclidean metric learning on symmetric positive-definite manifold. IEEE Trans. on Cybernetics, 2022. DOI: 10.1109/TCYB.2022.3178412.
46	ZHANG X Y, QIU D Y, CHEN F Support vector machine with parameter optimization by a novel hybrid method and its application to fault diagnosis. Neurocomputing, 2015, 149, 641- 651. doi: 10.1016/j.neucom.2014.08.010
47	WANG L T, ZHANG J X, ZHANG J H, et al Application of crow search algorithm in SVM parameter optimization. Computer Engineering and Applications, 2019, 55 (21): 213- 218.
48	MAITY A, PRAKASAM P, BHARGAVA S Machine learning based KNN classifier: towards robust, efficient DTMF tone detection for a noisy environment. Multimedia Tools and Applications, 2021, 80 (19): 29765- 29784. doi: 10.1007/s11042-021-11194-3

Algorithm	Parameter setting
LSHADE	H=3, MF=0.5, p_init=0.11, N_init=200, N_min=150, D=2
CoBiDE	pb=0.4, ps=0.5, D=2
DE	F=0.5, Cr=0.5, D=2
SSA	Leader position update probability=0.5
PSO	C₁=1.5, C₂=1.5, D=2, Inertia factor=0.3
HHO	$ \alpha $ =0.01, $ \beta $ =1.5, J=2(1-rand)
GWO	a=2−2t/t_max
GSA	α=20, G0=100, R_norm=2, R_power=1

Number	Algorithm	Parameter setting
1	DPC	Reference [36]
2	FCM	The index of the membership matrix is 2, the maximum number of iterations is 200, and the minimum membership is 1.0e−5
3	GMM	The non-negative regularization number is 1.0e−5
4	CLA	Reference [37]
5	LGC	Reference [37]
6	K-means	Use Euclidean distance, the number of clusters is 4
7	GBK-Means	Reference [38]
8	C-LSHADE-Means	Use Euclidean distance, the number of clusters is 4, the maximum number of iterations is 200, CR=0.5,F=0.5, the initial population is 200, and the minimum population is 150

Data	Index	DPC	FCM	GMM	CLA	GLA	K-means	CBK-Means	C-LSHADE-Means
UCI Data	Ac/%	63.24	74.57	80.35	84.1	84.2	75.43	77.43	86.86
	DB	0.6584	0.7850	0.7701	0.635	0.635	0.7627	0.750	0.7526
	CH	237.3047	339.5852	283.9508	336.248	336.249	340.2413	286.260	340.2610
	Sil	0.2468	0.4160	0.4084	0.402	0.410	0.4192	0.383	0.4348
	Rank	8/8	3/8	5/8	6/8	4/8	2/8	7/8	1/8

Algorithm	Parameter setting
HSVM	H=2, C=100, $ \alpha = 1.0{\rm{e}} - 5 $
CSA-HSVM	Fl=2.5, AP=0.1, iter=100, NP=20, C=100, $\alpha = 1.0{\rm{e}} - 5$
KNN	K=4
LVQ	$ \eta = 0.01 $ , max_epoch=300, Num_Compet=20
SAE-HSVM	Number_AE=2,H=2, C=100, $ \alpha = 1.0{\rm{e}} - 5 $
SAE-LVQ	Number_AE=2, $ \eta = 0.01 $ , max_epoch=300, Num_Compet=20

Classifier	Mean (SD)
Classifier	Accuracy/%	RMSE	MAPE/%	Kappa	Time
HSVM	86.704(4.29e−01)	0.1208 (1.12e−02)	4.0262(4.61e−01)	0.7912 (6.4e−03)	9.183e−05 (1.862e−05)
LVQ	94.663(2.81e−01)	0.0468 (4.3e−03)	2.6607(1.95e−01)	0.9113 (4.7e−03)	3.412e−05 (3.247e−06)
CSA-SVM	94.10(7.43e−01)	0.062 (9.7e−03)	4.681(4.56e−01)	0.904 (1.20e−02)	3.16e−04 (7.34e−04)
KNN	88.015(6.13e−01)	0.055 (1.27e−02)	6.99(7.43e−01)	0.804 (1.74e−02)	7.674e−05 (5.152e−05)
SAe−HSVM	96.910(2.81e−01)	0.0356 (5.8e−03)	2.1223(5.49e−01)	0.9486 (4.6e−03)	4.435e−04 (6.882e−07)
SAe−LVQ	99.251(1.62e−01)	0.0037 (1.6e−03)	0.5384(1.46e−01)	0.9876 (2.7e−3)	1.024e−04 (1.292e−05)
