Time-delay nonlinear model based on interval grey number and its application

doi:10.23919/JSEE.2022.000039

Journal of Systems Engineering and Electronics ›› 2022, Vol. 33 ›› Issue (2): 370-380.doi: 10.23919/JSEE.2022.000039

收稿日期:2020-10-12 出版日期:2022-05-06 发布日期:2022-05-06

Time-delay nonlinear model based on interval grey number and its application

Pingping XIONG^1,*(), Shiting CHEN²(), Shuli YAN¹()

¹ School of Management Science and Engineering, Nanjing University of Information Science and Technology, Nanjing 210044, China
² College of Mathematics and Statistics, Nanjing University of Information Science and Technology, Nanjing 210044, China

Received:2020-10-12 Online:2022-05-06 Published:2022-05-06
Contact: Pingping XIONG E-mail:xpp8125@163.com;1780458169@qq.com;yshuli@126.com
About author:|XIONG Pingping was born in 1981. She received her M.S. degree from Faculty of Mathematics, Huazhong University of Science and Technology and Ph.D. degree in School of Economics and Management from Nanjing University of Aeronautics and Astronautics. She is currently a professor in Nanjing University of Information Science and Technology. Her current research interests include grey system, system evaluation and prediction analysis, and financial statistical analysis. E-mail: xpp8125@163.com||CHEN Shiting was born in 1995. She received her B.S. degree from Nanjing University of Information Science and Technology in 2018. She received her M.S. degree from the School of Mathematics and Statistics, Nanjing University of Information Science and Technology in 2021. Her main research is grey system. E-mail: 1780458169@qq.com||YAN Shuli was born in 1982. She received her M.S. degree in School of Science from Wuhan University of Technology and Ph.D. degree in School of Economics and Management from Nanjing University of Aeronautics and Astronautics. She is currently an associate professor in Nanjing University of Information Science and Technology. Her current research interests include grey system, decision making, system evaluation, and prediction analysis. E-mail: yshuli@126.com
Supported by:
This study was supported by the National Natural Science Foundation of China (71701105; 71901191), the Major Program of the National Social Science Fund of China (17ZDA092), the Key Research Project of Philosophy and Social Sciences in Universities of Jiangsu Province (2018SJZDI111), and Jiangsu Provincial Government Scholarship for studying abroad.

摘要/Abstract

Abstract:

In this paper, an optimization model is proposed to simulate and predict the current situation of smog. The model takes the interval grey number sequence with the known possibility function as the original data, and constructs a time-delay nonlinear multivariable grey model MGM $(1,m|\tau ,\gamma )$ based on the new kernel and degree of greyness sequences considering its time-delay and nonlinearity. The time-delay parameter is determined by the maximum value of the grey time-delay absolute correlation degree, and the nonlinear parameter is determined by the minimum value of average relative error. In order to verify the feasibility of the model, this paper uses the smog related data of Nanjing city for simulation and prediction. Compared with the other four models, the new model has higher simulation and prediction accuracy.

Key words: kernel, degree of greyness, time-delay, nonlinear, smog

. [J]. Journal of Systems Engineering and Electronics, 2022, 33(2): 370-380.

Pingping XIONG, Shiting CHEN, Shuli YAN. Time-delay nonlinear model based on interval grey number and its application[J]. Journal of Systems Engineering and Electronics, 2022, 33(2): 370-380.

图/表 9

Data	$ \otimes _1^{(0)}$	$ \otimes _2^{(0)}$
Dec.24	$f_1^{ - 11}[74.00,90.67,107.33,124.00]$	$f_2^{ - 11}[4.20,6.60,9.00,11.40]$
Dec.25	$f_1^{{\text{ ? 10}}}[74.00,95.67,117.33,139.00]$	$f_2^{{\text{ ? 10}}}[3.70,6.27,8.83,11.40]$
Dec.26	$f_1^{{\text{ ? 9}}}[82.00,101.00,120.00,139.00]$	$f_2^{{\text{ ? 9}}}[3.70,6.27,8.83,11.40]$
Dec.27	$f_1^{ {\text{ ? 8}}}[87.00,104.33,121.67,139.00]$	$f_2^{{\text{ ? 8}}}[3.70,5.10,6.50,7.90]$
Dec.28	$f_1^{ {\text{ ? 7}}}[87.00,104.00,121.67,139.00]$	$f_2^{{\text{ ? 7}}}[3.20,4.43,5.67,6.90]$
Dec.29	$f_1^{ {\text{ ? 6}}}[87.00,104.33,121.67,139.00]$	$f_2^{{\text{ ? 6}}}[2.50,3.83,5.17,6.50]$
Dec.30	$f_1^{ {\text{ ? 5}}}[69.00,92.33,115.67,139.00]$	$f_2^{{\text{ ? 5}}}[2.50,3.83,5.17,6.50]$
Dec.31	$f_1^{{\text{ ? 4}}}[51.00,75.00,99.00,123.00]$	$f_2^{{\text{ ? 4}}}[2.50,9.00,15.50,22.00]$
Jan.1	$f_1^{{\text{ ? 3}}}[51.00,75.00,99.00,123.00]$	$f_2^{{\text{ ? 3}}}[2.50,9.60,16.70,23.80]$
Jan.2	$f_1^{{\text{ ? 2}}}[51.00,75.00,99.00,123.00]$	$f_2^{{\text{ ? 2}}}[2.50,9.60,16.70,23.80]$
Jan.3	$f_1^{{\text{ ? 1}}}[51.00,75.00,99.00,123.00]$	$f_2^{{\text{ ? 1}}}[2.50,9.60,16.70,23.80]$
Jan.4	$f_1^0[51.00,59.67,68.33,77.00]$	$f_2^0[4.60,11.00,17.40,23.80]$
Jan.5	$f_1^1[51.00,59.67,68.33,77.00]$	$f_2^1[8.80,13.80,18.80,23.80]$
Jan.6	$f_1^2[53.00,61.00,69.00,77.00]$	$f_2^2[8.80,13.80,18.80,23.80]$
Jan.7	$f_1^3[58.00,64.33,70.67,77.00]$	$f_2^3[8.80,11.30,13.80,16.30]$
Jan.8	$f_1^4[58.00,64.33,70.67,77.00]$	$f_2^4[8.80,12.47,16.13,19.80]$
Jan.9	$f_1^5[57.00,63.67,70.33,77.00]$	$f_2^3[8.80,13.93,19.07,24.20]$
Jan.10	$f_1^6[57.00,63.67,70.33,77.00]$	$f_2^6[8.80,13.93,19.07,24.20]$
Jan.11	$f_1^7[57.00,63.67,70.33,77.00]$	$f_2^7[9.50,14.40,19.30,24.20]$
Jan.12	$f_1^8[57.00,63.67,70.33,77.00]$	$f_2^8[10.60,15.13,19.67,24.20]$
Jan.13	$f_1^9[57.00,69.00,81.00,93.00]$	$f_2^9[10.60,15.13,19.67,24.20]$
Jan.14	$f_1^{10}[57.00,69.00,81.00,93.00]$	$ f_2^{10}[10.60,15.13,19.67,24.20] $
Jan.15	$f_1^{11}[57.00,71.00,85.00,99.00]$	$ f_2^{11}[10.60,13.33,16.07,18.80] $
Jan.16	$f_1^{12}[71.00,82.33,93.67,105.00]$	$ f_2^{12}[6.60,9.30,12.00,14.70] $
Jan.17	$f_1^{13}[71.00,82.33,93.67,105.00]$	$ f_2^{13}[6.60,9.30,12.00,14.70] $

Value	$n$	Actual value		Model 1		Model 2		Model 3		Model 4
Value	$n$	AQI	Visibility/km	AQI	Visibility/km	AQI	Visibility/km	AQI	Visibility/km	AQI	Visibility/km
Simulated value	1	[51.00,77.00]	[8.80,23.80]	[51.85,69.77]	[9.27,23.85]	[51.00,77.00]	[8.80,23.80]	[51.00,77.00]	[8.80,23.80]	[51.00,77.00]	[8.80,23.80]
	2	[53.00,77.00]	[8.80,23.80]	[52.96,72.38]	[9.24,23.43]	[56.32,72.71]	[8.57,21.29]	[58.28,69.78]	[11.33,20.77]	[54.90,76.28]	[9.58,17.31]
	3	[58.00,77.00]	[8.80,16.30]	[54.08,75.00]	[9.21,23.00]	[55.00,75.19]	[9.25,21.42]	[59.97,74.53]	[8.87,16.19]	[58.88,76.86]	[9.08,16.14]
	4	[58.00,77.00]	[8.80,19.80]	[55.19,77.61]	[9.17,22.58]	[55.04,77.87]	[9.47,20.99]	[59.46,76.53]	[9.20,19.58]	[58.24,76.08]	[9.55,19.74]
	5	[57.00,77.00]	[8.80,24.20]	[56.31,80.23]	[9.14,22.16]	[55.70,79.42]	[9.16,21.77]	[57.94,76.28]	[11.18,19.88]	[57.93,76.69]	[9.62,23.52]
	6	[57.00,77.00]	[8.80,24.20]	[57.42,82.84]	[9.10,21.74]	[56.45,80.64]	[8.94,22.82]	[57.87,76.30]	[10.61,20.33]	[57.90,76.39]	[9.72,23.60]
	7	[57.00,77.00]	[9.50,24.20]	[58.54,85.46]	[9.07,21.31]	[57.25,82.11]	[8.95,23.56]	[57.76,76.41]	[10.73,21.36]	[57.92,76.23]	[10.33,23.84]
	8	[57.00,77.00]	[10.60,24.20]	[59.65,88.07]	[9.04,20.89]	[57.99,83.71]	[9.22,24.13]	[58.25,76.09]	[11.13,23.41]	[58.19,76.82]	[11.18,23.83]
	9	[57.00,93.00]	[10.60,24.20]	[60.77,90.69]	[9.00,20.47]	[58.63,86.42]	[9.84,23.80]	[64.56,85.55]	[11.31,23.25]	[62.17,83.24]	[11.29,23.68]
	10	[57.00,93.00]	[10.60,24.20]	[61.88,93.30]	[8.97,20.04]	[59.57,90.10]	[10.42,22.73]	[62.32,87.02]	[11.84,21.84]	[65.27,81.23]	[11.54,23.07]
	11	[57.00,99.00]	[10.60,18.80]	[63.00,95.92]	[8.93,19.62]	[61.28,94.74]	[10.54,20.84]	[65.05,89.78]	[10.83,18.71]	[66.26,79.90]	[11.28,18.80]
	12	[71.00,105.00]	[6.60,14.70]	[64.11,98.53]	[8.90,19.20]	[65.35,101.50]	[8.94,17.24]	[73.56,104.35]	[6.92,14.56]	[77.89,86.97]	[7.03,14.60]
	13	[71.00,105.00]	[6.60,14.70]	[65.23,101.15]	[8.87,18.77]	[71.43,109.59]	[5.80,12.70]	[72.37,103.77]	[7.03,12.27]	[79.09,84.06]	[7.08,14.59]
Predicted value	14	[71.00,105.00]	[6.60,14.70]	[66.34,103.76]	[8.83,18.35]	[76.83,116.60]	[3.19,9.08]	[72.34,105.82]	[7.30,10.67]	[72.86,75.41]	[6.52,15.57]
Predicted value	15	[71.00,105.00]	[6.60,14.70]	[67.46,106.38]	[8.80,17.93]	[81.58,122.74]	[1.13,6.22]	[63.96,104.16]	[7.17,9.55]	[84.75,84.78]	[9.78,15.68]

参考文献 46

1	SUN X Z, WANG K, LI B, et al Exploring the cause of PM 2.5 pollution episodes in a cold metropolis in China. Journal of Cleaner Production, 2020, 256, 120275.
2	ZHAO Q, YUAN C H Did haze pollution harm the quality of economic development?—An empirical study based on China’s PM2.5 concentrations. Sustainability, 2020, 12 (4): 1607.
3	LEI Y H Hazards of haze and countermeasures. Applied Mechanics and Materials, 2014, 507, 817- 820.
4	GAO L N, CAO L J, ZHANG Y, et al Re-evaluating the distribution and variation characteristics of haze in China using different distinguishing methods during recent years. Science of the Total Environment, 2020, 732, 138905. doi: 10.1016/j.scitotenv.2020.138905
5	WANG F C, ZHENG P, DAI J L, et al Fault tree analysis of the causes of urban smog events associated with vehicle exhaust emissions: a case study in Jinan, China. Science of the Total Environment, 2019, 668, 245- 253.
6	ZHANG J J, CHU X H, MEI T Causes of continuous haze pollution in Jiujiang City. Meteorological and Environmental Research, 2020, 11 (3): 16- 20.
7	YAN J C, LIANG X G, LIN M G, et al A hybrid features learning model for single image haze prediction. Signal, Image and Video Processing, 2018, 12 (11): 1- 8.
8	YIN Z C, WANG H J Statistical prediction of winter haze days in the north China plain using the generalized additive model. Journal of Applied Meteorology and Climatology, 2017, 56 (9): 2411- 2419. doi: 10.1175/JAMC-D-17-0013.1
9	SHAWKI D, FIELD R D, TIPPETT M K, et al Long-lead prediction of the 2015 fire and haze episode in Indonesia. Geophysical Research Letters, 2017, 44 (19): 9996- 10005. doi: 10.1002/2017GL073660
10	ZHANG M, LIU X X, DING Y T, et al How does environmental regulation affect haze pollution governance?—An empirical test based on Chinese provincial panel data. Science of the Total Environment, 2019, 695, 133905. doi: 10.1016/j.scitotenv.2019.133905
11	ZHANG M, LI H, XUE L Z, et al Using three-sided dynamic game model to study regional cooperative governance of haze pollution in China from a government heterogeneity perspective. Science of the Total Environment, 2019, 694, 133559. doi: 10.1016/j.scitotenv.2019.07.365
12	LI H, ZHANG M, LI C, et al Study on the spatial correlation structure and synergistic governance development of the haze emission in China. Environmental Science and Pollution Research International, 2019, 26 (12): 12136- 12149. doi: 10.1007/s11356-019-04682-5
13	KONG Y W, SHENG L F, LI Y P, et al Improving PM2. 5 forecast during haze episodes over China based on a coupled 4D-LETKF and WRF-Chem system. Atmospheric Research, 2021, 249, 105366.
14	ZHANG M D, YANG J W, ZHANG W M, et al Analysis, prediction and application of Beijing smog based on ARIMA. Statistics and Application, 2019, 8 (2): 381- 393. doi: 10.12677/SA.2019.82043
15	LIU D Y, HE Y D, WANG Q R Urban spatial structure evolution and smog management in China: a re-examination using nonparametric panel model. Journal of Cleaner Production, 2020, 285, 124847.
16	FU B, GAO X H, WU L F Grey relational analysis for the AQI of Beijing, Tianjin, and Shijiazhuang and related countermeasures. Grey Systems-Theory and Application, 2018, 8 (2): 156- 166. doi: 10.1108/GS-12-2017-0046
17	ZHANG R H, SUN B, LIU M Y, et al Haze pollution, new-type urbanization and regional total factor productivity growth: based on a panel dataset involving all 31 provinces within the territory of China. Kybernetes, 2020, 50 (5): 1357- 1378.
18	LI S L, ZENG B, MA X, et al A novel grey model with a three-parameter background value and its application in forecasting average annual water consumption per capita in urban areas along the Yangtze River Basin. Journal of Grey System, 2020, 32 (1): 118- 132.
19	KARIMI T, HOJATI A Designing a medical rule model system by using rough–grey modeling. Grey Systems: Theory and Application, 2020, 10 (4): 513- 527. doi: 10.1108/GS-02-2020-0017
20	DING S, XU N, YE J, et al Estimating Chinese energy-related CO₂ emissions by employing a novel discrete grey prediction model . Journal of Cleaner Production, 2020, 259, 120793. doi: 10.1016/j.jclepro.2020.120793
21	DUAN J L, JIAO F, ZHANG Q S An improvement of GM (1, N) model based on support vector machine regression with nonlinear cross effects . Symmetry, 2019, 11 (5): 604. doi: 10.3390/sym11050604
22	XIE W L, LIU C, WU W Z The fractional non-equidistant grey opposite-direction model with time-varying characteristics. Soft Computing, 2020, 24, 6603- 6612. doi: 10.1007/s00500-020-04799-7
23	ZHAI J, SHENH J M, FENG Y J The grey model MGM(1, n) and its application . Systems Engineering: Theory and Practice, 1997, 17 (5): 109- 113.
24	YUAN Z H, GUO F, QI X X Fault prediction methods study of machinery based on optimized background value MGM(1, m) model . Applied Mechanics and Materials, 2014, 3360, 1513- 1516.
25	GE P F Application of optimization algorithm for unequal time interval MGM (1, N) in engineering survey . Geomatics Science and Technology, 2020, 8 (2): 68- 77. doi: 10.12677/GST.2020.82009
26	XIONG P P, HE Z Q, CHEN S T, et al A novel GM(1, N) model based on interval gray number and its application to research on smog pollution . Kybernetes, 2020, 49 (3): 753- 778.
27	XIONG P P, HUANG S, PENG M, et al. Examination and prediction of fog and haze pollution using a multi-variable grey model based on interval number sequences. Applied Mathematical Modelling, 2020, 77(Part 2): 1531−1544.
28	ZHANG F, TAN S W, ZHANG L L, et al. Fault tree interval analysis of complex systems based on universal grey operation. Complexity, 2019. DOI: 10.1155/2019/1046054.
29	ZENG B, LI C, CHEN G, et al Verhulst model of interval grey number based on information decomposing and model combination. Journal of Applied Mathematics, 2013, 2013, (6): 1- 8. doi: 10.1155/2013/472065
30	ZHAO L M, ZENG B Prediction modeling method of interval grey number based on different type whitenization weight functions. Applied Mechanics and Materials, 2013, 411, 2074- 2080.
31	LI Y, GUO S D, LI J Prediction model of three-parameter interval grey number based on kernel and double information domains. Grey Systems−Theory and Application, 2020, 10 (4): 455- 465. doi: 10.1108/GS-09-2019-0030
32	MA X, MEI X, WU W Q, et al A novel fractional time delayed grey model with Grey Wolf Optimizer and its applications in forecasting the natural gas and coal consumption in Chongqing China. Energy, 2019, 178, 487- 507. doi: 10.1016/j.energy.2019.04.096
33	LIU P L Stability of continuous and discrete time-delay grey systems. International Journal of Systems Science, 2001, 32 (7): 947- 952. doi: 10.1080/00207720010005636
34	SAHIN U Future of renewable energy consumption in France, Germany, Italy, Spain, Turkey and UK by 2030 using optimized fractional nonlinear grey Bernoulli model. Sustainable Production and Consumption, 2021, 25 (1): 1- 14.
35	YUAN Y B, LI Q, YUAN X H, et al A SAFSA- and metabolism-based nonlinear grey Bernoulli model for annual water consumption prediction. Iranian Journal of Science and Technology, 2020, 44 (1): 1- 11. doi: 10.1007/s40995-019-00800-7
36	XIE M, WU L F, LI B, et al A novel hybrid multivariate nonlinear grey model for forecasting the traffic-related emissions. Applied Mathematical Modelling, 2020, 77 (2): 1242- 1254.
37	ZHENG C L, WU W Z, XIE W L, et al Forecasting the hydroelectricity consumption of China by using a novel unbiased nonlinear grey Bernoulli model. Journal of Cleaner Production, 2021, 278, 123903. doi: 10.1016/j.jclepro.2020.123903
38	FU Z H, ZHENG R J Time-delay multivariable GM(1, N) coordination degree model and its application . Statistics and Decision, 2018, 34 (13): 77- 80.
39	CAI G Q, AN T Y, ZHOU S Q Grey series time-delay predicting model in state estimation for power distribution networks. Journal of Harbin Institute of Technology, 2003, 41 (2): 120- 123.
40	LI M X, LIAO R Q, DONG Y Adaptive determination of time delay in grey prediction model with time delay. IIETA, 2019, 24 (5): 519- 524.
41	ZHOU K Gray nonlinear water environment management model and its application based on genetic algorithm solution. Yangtze River, 2019, 50 (5): 20- 24, 40.
42	GUO X J, LIU S F, YANG Y J A prediction method for plasma concentration by using a nonlinear grey Bernoulli combined model based on a self-memory algorithm. Computers in Biology and Medicine, 2018, 105, 81- 91.
43	SHU H, WANG W P, XIONG P P Kernel and greyness of interval grey number under known whitening weight function. Control and Decision, 2017, 32 (12): 2190- 2194.
44	XIONG P P, ZHANG Y, XING Z, et al Multivariable time-delay discrete MGM(1, m, τ) model and its application . Statistics and Decision, 2019, 35 (8): 18- 22.
45	FAN X S, XIAO X P. Method to find τ, r in GM(1, 1\| τ, r) and its application. Journal of Wuhan University of Technology (Information and Management Engineering), 2013, 35(4): 536−539. (in Chinese)
46	LEWIS C D. Industrial and business forecasting method. London: Butter-worth-Heinemann, 1982.

Average relative error/%	Prediction accuracy
<10	Higher
10?20	High
20?50	Medium
>50	Low

Value	n	AQI	Visibility /km
Simulated value	1	[51.00,77.00]	[8.80,23.80]
	2	[53.37,76.62]	[9.14,19.91]
	3	[58.28,76.75]	[8.86,16.25]
	4	[58.19,76.73]	[8.83,19.67]
	5	[57.56,76.81]	[8.90,21.89]
	6	[57.55,76.97]	[9.18,19.83]
	7	[57.03,76.63]	[10.12,20.31]
	8	[57.34,76.74]	[10.63,22.80]
	9	[59.19,83.46]	[10.63,24.06]
	10	[61.40,81.84]	[10.64,24.17]
	11	[58.00,80.94]	[10.65,18.72]
	12	[71.72,90.83]	[6.67,14.63]
	13	[73.40,91.35]	[6.66,14.65]
Predicted value	14	[72.69,90.34]	[6.51,15.39]
Predicted value	15	[74.54,90.14]	[6.66,15.75]

Erorr	$n$	AQI		Visibility
Erorr	$n$	L/%	U/%	L/%	U/%
Simulated error	1	0.00	0.00	0.00	0.00
	2	0.70	0.50	3.83	16.34
	3	0.48	0.32	0.70	0.29
	4	0.32	0.35	0.34	0.64
	5	0.97	0.25	1.18	9.55
	6	0.97	0.04	4.31	18.05
	7	0.05	0.49	6.54	16.09
	8	0.60	0.34	0.30	5.80
	9	3.83	10.26	0.31	0.59
	10	7.71	12.00	0.33	0.12
	11	1.76	18.25	0.48	0.44
	12	1.02	13.49	1.07	0.45
	13	3.38	13.00	0.84	0.34
Average simulation error		1.68	5.33	1.56	5.28
Predicted error	14	2.37	13.96	1.38	4.72
Predicted error	15	4.99	14.15	0.90	7.15
Average prediction error		3.68	14.06	1.14	5.94

Error	$n$	Model 1				Model 2				Model 3				Model 4
		AQI		Visibility		AQI		Visibility		AQI		Visibility		AQI		Visibility
		L/%	U/%	L/%	U/%	L/%	U/%	L/%	U/%	L/%	U/%	L/%	U/%	L/%	U/%	L/%	U/%
Simulated error	1	1.66	9.39	5.39	0.21	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00
	2	0.07	5.99	5.00	1.57	6.26	5.58	2.61	10.55	9.95	9.37	28.73	12.71	3.59	0.93	8.88	27.28
	3	6.77	2.60	4.61	41.13	5.17	2.34	5.09	31.43	3.40	3.20	0.84	0.65	1.51	0.19	3.17	0.97
	4	4.84	0.80	4.23	14.05	5.11	1.14	7.65	6.02	2.51	0.60	4.51	1.12	0.42	1.19	8.47	0.31
	5	1.22	4.19	3.84	8.44	2.29	3.14	4.09	10.06	1.65	0.94	27.05	17.85	1.63	0.40	9.29	2.83
	6	0.74	7.59	3.45	10.19	0.96	4.73	1.62	5.70	1.52	0.91	20.53	15.97	1.58	0.80	10.46	2.46
	7	2.69	10.99	4.53	11.93	0.44	6.64	5.77	2.63	1.33	0.77	12.96	11.74	1.62	1.00	8.78	1.50
	8	4.65	14.38	14.75	13.68	1.74	8.72	12.98	0.28	2.19	1.19	5.04	3.27	2.08	0.23	5.47	1.53
	9	6.61	2.48	15.08	15.43	2.86	7.07	7.14	1.65	13.25	8.01	6.70	3.91	9.07	10.49	6.47	2.16
	10	8.56	0.33	15.40	17.18	4.51	3.12	1.72	6.06	9.33	6.43	11.71	9.76	14.52	12.66	8.86	4.69
	11	10.52	3.11	15.72	4.36	7.51	4.31	0.58	10.83	14.12	9.32	2.20	0.47	16.25	19.29	6.41	0.02
	12	9.70	6.16	34.85	30.59	7.96	3.34	35.39	17.30	3.60	0.61	4.91	0.94	9.70	17.17	6.49	0.66
	13	8.13	3.67	34.33	27.71	0.61	4.37	12.19	13.61	1.92	1.17	6.47	16.52	11.39	19.95	7.31	0.75
Average simulation error		5.09	5.51	12.40	15.11	3.49	4.19	7.45	8.93	4.98	3.27	10.13	7.30	5.64	6.48	6.93	3.47
Predicted error	14	6.56	1.18	33.82	24.84	8.22	11.05	51.69	38.24	1.89	0.78	10.59	27.43	2.62	28.18	1.24	5.90
Predicted error	15	4.99	1.31	33.30	21.96	14.90	16.90	82.95	57.65	9.92	1.10	8.69	35.00	19.37	19.26	48.20	6.69
Average prediction error		5.78	1.25	33.56	23.40	11.56	13.97	67.32	47.95	5.90	0.94	9.64	31.22	10.99	23.72	24.72	6.30
